Audiocenter GT515A 15" 2200W 136dB Powered Speaker

Audiocenter GT515A speaker integrated with massive power, switching power supply technology and DSP. With built-in DSP control technology, all functions such as EQ adjustment, phase, correction, delay, limiter, etc., can be easily realized. High-efficiency Class D amplifier technology, light weight and more compact. With 3 presets of GTA series, users can recall different presets for different applications to get the right sound performance. Powerful protection function with built-in DSP processing circuit that can give strong limiter protection to HF and LF separately. Advanced AD/DA converter. Signal sampling rate of 48KHz and 24-bit precision. Device to ensure clear and clean sound. There are three presets in GTA series full-range speakers for users to remember for use in different applications. For live performances and use as a monitor on stage. The Voice preset is used for business activities, presentations, and public speeches, etc. LF BOOST preset (only available for GT512A and GT515A) Ideal for DJ and club applications, providing an extra boost in the low frequencies. The perfect combination for use with Audiocenter Sub, achieving proper phase alignment.

Type: DSP-controlled full-range active speaker
Frequency response (-6 dB): 42Hz-20kHz
Calculated maximum SPL/1M (continuous/peak): 130 dB/136 dB
LF: Custom 15″ transducer, 3.0 voice coil
HF: Custom transducer, 1.75″ voice coil and 1.0″ output
Horizontal coverage: 90°/60°
Vertical Coverage: 60°/90°
Power (peak): 2200W
Frequency response (1W 8Ω 2ch): 20 Hz-20 kHz (±0.5 dB)
Intermodulation distortion: ＜0.05%
Total harmonic distortion: ＜0.05%
Protection: DC protection, short circuit protection, overheat protection, input overload protection, output overload protection, soft start protection, overvoltage protection, undervoltage protection
Cooling system: Fan cooling, air convection
Processor: 48 kHz signal sampling rate, FIR filtering
Presets: MAIN, LF BOOST, C/SUB
Signal input: 2× XLR female, 6.35 mono socket
Signal output: 2× XLR male
Power input: IEC power connector
Working voltage: 100V~130V or 220V~240V(±10%,50/60Hz)
Consumption (1/8 output power): 95W
Cabinet material: CNC machined plywood
Monitor Angle: Symmetrical monitoring angle of 45
Hanging hardware: M8 screw
Pole Mount: Base hole Φ35mm, 0° or 10° options.
Dimensions (W×H×D): 421×696×416mm
Net weight: 24.0Kg
